Ubiquiti Rocket M2 (2.4GHz) 802.11n WiFi AP & PtP Wireless Bridge

Key Features

• Carrier grade base station radio

• Connect multiple remote locations on the one network (+50km possible)

• Share Internet connection between buildings, remote sites, etc.

• Up to 600mW output power, +300Mbps 802.11n 2x2MIMO capable

• 24VDC POE Injector & 240V AC Adaptor included.

Usage

• AirMAX ac supports high data rates,which require dense modulation: 256QAM – a significant increase from 64QAM, which is used in the original airMAX range

• With their use of proprietary airMAX ac technology, airMAX ac products supports up to 330+ Mbps (maximum 40 MHz channel width) real TCP/IP throughput – up to triple the throughput of standard airMAX products

• While Rocket is capable of some amazing things, the 2AC model is typically coupled with omnidirectional antennas to provide high powered 802.11n WiFi access in a 360 degree range

• Unlike the UniFi AP-Outdoor, this unit does not require a controller and is configured using only it's integrated HTTP interface

• The Rocket combines the “brains” in one robust unit; allowing it to be paired with any 2.4GHz (M2) WiFi antenna on the market. This versatility gives network architects unparalleled flexibility and convenience.

High Speed Network Sharing

• This is a transparent data-link layer bridge, not a routed bridge - this means that you are creating a virtual ethernet cable between the two facilities, making network setup incredibly simple - no routing configuration, all protocols (DHCP, DNS, etc) just work

• Management of the Ubiquiti device couldn't be easier with SSH and SNMP protocol support, as well as a very intuitive HTTP interface

• The units are powered via Power over Ethernet (PoE) - simply plug one end of the Ethernet cable into the Rocket, and the other into the PoE Injector (which is plugged into AC power)

• This allows one cable to both power the unit and also carry network traffic

• We recommend using Cat6 Outdoor UV Shielded Cable with this unit.

Read more

• Specification Sheet

• Quick Start Installation Manual

• AirOS Complete User Guide

• Ubiquiti Networks Case Studies
