Ubiquiti airFiber X 2.4GHz MIMO Microwave Radio



Key Features



  • Class-licensed 2.4GHz ISM band (unlicensed-band)

  • 10.6bps/Hz spectral efficiency

  • 1/4QPSK to 256QAM adaptive modulation

  • +500Mbps throughput, +50km range

  • 10/20/30/40/50MHz with 1MHz granular CF control

  • 24VDC 1A GigE PoE injector & Australian 240VAC power cord included.



Multi-channel Coding



  • Newly developed for airFiber AF2X, the patent-pending xRT feature uses an innovative, adaptive multi-channel coding scheme to enhance radio transceiver performance, thereby maximising your link budget and spectrum utilisation – while still maintaining regulatory compliance

  • This results in links that can span distances from 10m to over 100km.



Innovative Proprietary Modem Technology



  • Ubiquiti’s innovative proprietary modem technology was purpose-built to address the specific challenges of outdoor, PtP (Point-to-Point) bridging and high-performance network backhauls

  • Every aspect of the radio has been carefully simulated and designed to optimise range, speed, and latency performance in the harshest RF noise environments.



Synchronous Data Transmission and Reception



  • Conventional wireless standards impose a latency by having to receive a packet before a packet is transmitted. airFiber can transmit data synchronously without any wait time

  • airFiber features traditional TDD and FDD modes of operation in addition to the proprietary Hybrid Division Duplexing (HDD) mode, which provides a breakthrough in range and spectral efficiency performance

  • Based on the ranging algorithm built into the air protocol, the airFiber radios use patent-pending HDD technology to calculate the propagation delay and know when each radio can transmit and receive, so they send packets in precise synchronisation

  • Packet transmission latency is virtually eliminated.



Read More





(AF-2X)

SKU AF-2X
Brand Ubiquiti
Shipping Weight 0.0450kg
Shipping Width 0.110m
Shipping Height 0.110m
Shipping Length 0.265m
Shipping Cubic 0.003207000m3
