Ubiquiti EdgeSwitch - 48 Port, 750WM

Key Features

• (48) Gigabit RJ45 ports

• (2) SFP+ ports

• (2) SFP ports

• Non-blocking throughput: 70 Gbps

• Switching capacity: 140 Gbps

• Forwarding rate: 104.16 Mpps

• Maximum power consumption: 500W

• Supports POE+ IEEE 802.3at/af and 24V Passive PoE

• Rackmountable.

Usage

• Build and expand your network with Ubiquiti Networks® EdgeSwitch™, part of the EdgeMAX® line of products

• The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks

• The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

• The EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss

• For its total, non-blocking throughput, the 48-port models support up to 70 Gbps.

PoE+ Flexibility

• This EdgeSwitch model is available with 48 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V Passive PoE to simplify your infrastructure

• By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE

• For 24V Passive PoE devices, manually enable 24V passive PoE using the EdgeSwitch Configuration Interface.

Fiber Connectivity

• The EdgeSwitch provides fiber connectivity options for your growing networks

• For high-capacity uplinks, the 48-port models include two SFP and two SFP+ ports, providing up to 10 Gbps uplinks.
